LanDazzle 8S1P 21700 Battery Pack-Custom Battery Pack

8S1P 21700 battery pack

8S1P battery pack for FPV

8S1P battery pack application

8S1P 21700 battery pack

8S1P battery pack for FPV

8S1P battery pack application

21700 8S1P

Capacity: 5000mAh
Voltage: 28.8V
Weight: 0.63kg
Size(W*L*H): 45*89*80(mm)

⭕ High Rate

⭕ Full Tab

⭕ Long Battery Life

⭕ Fast Charging

⭕ Wide-temperature Performance

⭕ Customized Option

| Products details

Product Specifications

Model	Nominal Voltage （V）	Nominal Capacity （mAh）	Discharge Rate （C）	Connector Type	Dimension (WLH) (mm)	Weight(kg)
8S1P	28.8	5000	36	XT90/XH2.54-9P	458980	0.63

21700 Battery Pack 8S1P Features

Higher Voltage Platform: 28.8V nominal voltage (33.6V fully charged) for applications requiring higher operating voltages than standard 21.6V packs.
High Discharge Capability: Supports a high 125A maximum continuous discharge current for powerful performance.
Efficient Charging: Accepts up to a 10A max charge current for relatively quick recharge times.
Optimized Weight: Weighs approximately 630g, offering a good balance of power and portability for its voltage class.
Standard High-Power Connector: Features an XT90 output connector, suitable for its current rating, and an XH2.54-9P balance lead for 8S configuration.
Wide Operating Range: Reliable performance across a broad temperature range: discharge from -20°C to 60°C, charge from 0°C to 45°C.
Rigorous Safety Compliance: Designed and tested to meet GB, IEC, and UL safety standards, incorporating protection against overcharge, short-circuit, and physical abuse.

LanDazzle 21700 Battery Pack Series

Model	Nominal Voltage	Nominal Capacity	Discharge Rate	Connector Type	Dimension (WLH)	Weight
6S1P	21.6V	5000mAh	36C	XT60/XH2.54-7P	456880mm	0.47kg
6S2P	21.6V	10000mAh	36C	XT60/XH2.54-7P	5268150mm	0.9kg
6S3P	21.6V	15000mAh	36C	XT90/XH2.54-7P	6613180mm	1.33kg
6S3P	21.6V	15000mAh	36C	XT90/XH2.54-7P	6666210mm	1.33kg
6S4P	21.6V	20000mAh	36C	XT90/XH2.54-9P	8713180mm	1.75kg
8S2P	28.8V	10000mAh	36C	XT90/XH2.54-9P	4517380mm	1.21kg
8S3P	28.8V	15000mAh	36C	XT90/XH2.54-9P	6617380mm	1.75kg
8S4P	28.8V	20000mAh	36C	XT90/XH2.54-9P	8717380mm	2.34kg
12S4P	42.3V	20000mAh	36C	AS150/XH2.54-13P	87173150mm	3.44kg
14S6P	50.4V	30000mAh	36C	AS150/XH2.54-13P	129152150mm	5.97kg
18S6P	64.8V	30000mAh	36C	AS150/XH2.54-13P	129194150mm	7.84kg
24S6P	86.4V	30000mAh	36C	AS150/XH2.54-13P	129173220mm	10.45kg

| Demensional

| Applications

Delivery Drone

LanDazzle provides advanced lithium battery solutions specifically designed for delivery drones. Our batteries deliver high energy density, rapid discharge capability, and long-lasting performance, ensuring your drones achieve extended flight times, carry heavier payloads, and maintain reliable operation even in demanding conditions. With customizable options, we help businesses optimize their drone fleets for efficiency, safety, and maximum productivity.

Read more >>

Flashlight

LanDazzle offers the 26105 rechargeable C battery with a powerful 11000mAh capacity, engineered for high-performance flashlights. Designed to deliver long-lasting runtime and stable output, this battery ensures reliable power for outdoor adventures, emergency lighting, and professional applications.

Read more >>

Lawn Mower

LanDazzle offers high-performance lithium batteries designed specifically for lawn mowers. Our batteries provide longer runtime, consistent power output, and enhanced durability, ensuring your electric lawn mowers operate efficiently and reliably. With customizable options for voltage, capacity, and form factor, LanDazzle delivers battery solutions tailored to meet the demands of both residential and commercial lawn care equipment.

Read more >>

Humanoid Robot

Humanoid robots require powerful, reliable, and safe batteries to support continuous movement, advanced sensors, and intelligent interaction. LanDazzle offers custom lithium battery solutions designed for humanoid robots, ensuring long runtime, compact size, and high energy efficiency. With tailored designs, our batteries provide the stability and durability needed to bring humanoid robots to life.

Read more >>

AGV

Automated Guided Vehicles (AGVs) require reliable batteries with long cycle life, fast charging capability, and high safety standards. LanDazzle provides lithium battery solutions for AGVs, delivering high energy density, stable performance, and durable power support. From warehouse logistics to smart manufacturing and automated transport, our AGV batteries ensure efficiency, reduce downtime, and optimize operational costs.

Read more >>

Power Tools

Power tools demand high-performance, durable, and safe batteries to deliver consistent power for demanding tasks. At LanDazzle, we offer battery solutions engineered for maximum efficiency, long runtime, and seamless integration with your power tools.

Read more >>

| Downloads

Product Files:

File Name	Format	Size	Download
21700 8S1P	PDF	447KB	Download
