Requirements for FPV Drone Battery
| FPV Drone Function | Battery Requirements |
|---|---|
| High-Speed Flight | High discharge rate, supports bursts of high current |
| Agile Maneuvering | Lightweight, compact, and low internal resistance |
| Long Flight Time | High-capacity battery for extended operation |
| Quick Recharges | Supports fast charging without degrading lifespan |
| Extreme Conditions | Wide temperature range and safety protections |
LanDazzle FPV Battery Features
- High Discharge Rate
Supports up to 36C discharge rate, ideal for high-power applications requiring instant bursts of energy.
- Lightweight and Compact
Optimized design ensures minimal weight while maintaining high performance.
- High Capacity
Provides extended flight time, reducing the need for frequent recharging.
- Stable Voltage Output
Ensures reliable video transmission and consistent performance during flights.
- Fast Charging Support
Enables rapid charging up to 5C, minimizing downtime and maximizing efficiency.
Wide Temperature and Safety Range
Operates stably across extreme temperatures (-20°C to 75°C)
LanDazzle FPV Battery Solutions
LanDazzle FPV Battery Solutions deliver precision-engineered power with 21700 battery packs designed for high-performance drones.
Featuring high discharge capability, compact and lightweight construction, and long-lasting capacity, our 21700 battery packs provide stable voltage for smooth maneuvering and reliable FPV video transmission.
Equipped with advanced safety features and capable of operating across a wide temperature range, these batteries perform reliably in any flight scenario.
Additionally, LanDazzle offers customized 21700 battery solutions tailored to your drone’s specific needs—whether it’s racing, aerial photography, or professional FPV applications. Fast charging, extended lifespan, and intelligent protection systems ensure your drone stays in the air longer and performs at its peak every flight.
| Model | Voltage | C-Rate | Capacity | Width | Length | Height | Weight |
|---|---|---|---|---|---|---|---|
| 21700 6S1P | 21.6V | 36C | 5000mAh | 45mm | 68mm | 50mm | 0.47kg |
| 21700 6S2P | 21.6V | 36C | 10000mAh | 45mm | 131mm | 80mm | 0.9kg |
| 21700 6S3P | 21.6V | 36C | 15000mAh | 66mm | 131mm | 80mm | 1.33kg |
| 21700 8S2P | 28.8V | 36C | 10000mAh | 45mm | 89mm | 150mm | 1.21kg |
| 21700 8S3P | 28.8V | 36C | 15000mAh | 66mm | 173mm | 80mm | 1.75kg |
What Makes Our 21700 Battery Packs Suitable for Drones?
Traditional 21700 cells are rarely used in drones due to their weight, limited discharge rate, and lower space utilization compared to LiPo batteries. However, our advanced 21700 battery technology has successfully overcome these challenges, making them an ideal power source for UAV applications. Our 21700 battery packs break the limits of traditional cells. With 36C high discharge, they deliver the instant power drones need.
Smaller Size, Same Capacity
Our 21700 battery pack delivers 10,000mAh—the same capacity as a LiPo—but in a smaller, more compact footprint.
Optimized Space Utilization: Its compact size allows drones to make better use of internal space.
Lightweight Design: Reduced weight improves flight efficiency and extends airtime.
High Power Output: Despite the smaller size, it supports high-discharge performance for demanding UAV applications.
Conclusion: More power, less space, and better flight performance—all in one advanced 21700 battery pack.
Lighter Weight, Same Capacity
Our 21700 battery pack delivers 10,000mAh—the same capacity as a LiPo—but with a lighter weight of 900g compared to 1,140g for a LiPo pack.
Optimized Flight Efficiency: Lighter weight reduces the load on drones, improving maneuverability and overall performance.
Extended Airtime: Less weight means longer flight durations without sacrificing power.
High Discharge Performance: Despite the reduced weight, it still supports high-discharge demands for advanced UAV applications.
Conclusion: Same capacity, significantly lighter, and optimized for superior drone performance—all in one 21700 battery pack.
Higher Safety
Cylindrical battery packs have inherent safety advantages over lipo batteries, mainly due to their structure and materials:
Sturdy Metal Casing: Cylindrical cells feature metal shells that protect against impact, puncture, and compression, reducing short-circuit and fire risks compared to flexible lipo batteries.
Even Pressure Distribution: The cylindrical shape evenly distributes stress, while lipo batteries risk localized pressure that can cause internal short circuits.
Stable Internal Structure: Cylindrical cells maintain a fixed, stable structure, while lipo cells can shift under pressure or swelling, increasing short-circuit risk.
Better Thermal Management: Metal-cased cylindrical cells dissipate heat more evenly, while lipo batteries risk localized overheating and thermal runaway.
Our Customization Options
We provide a wide range of customization services.
- Voltage & Capacity Options
Customizable voltage (3.6V-43V or more)
Customizable capacity(5-30Ah or more), depending on size and flight time needs - Battery Size
Perfect-fit dimensions to match your drone’s battery compartment - Connector & Cable Types
Custom connectors
Cable length and gauge tailored to your drone layout - Temperature Tolerance
Custom chemistry for cold-weather or high-temperature use
Stable performance from -20°C to +75°C - Branding & Packaging
Private labeling
Custom packaging for retail-ready solutions
Ready to Power Your FPV Drones with High-Performance Batteries?
Whether you’re racing, filming, or exploring the skies, Lan Dazzle delivers safe, reliable, and precision-engineered battery solutions. Our lightweight, high-discharge LiPo batteries are designed to maximize flight time, ensure stable FPV video, and support agile maneuvering for any drone enthusiast or professional pilot.
👉 Let’s power your next flight.
Contact us today for a free consultation and discover how our custom FPV drone batteries can take your drone performance to the next level.
